America RegO LV6503B Series Large Capacity Low Pressure Second Stage Regulators
Brand: RegO
Model: LV6503B14 / LV6503B16
Size Specifications: 1½” ~ 2″ F.NPT
Product Code: RGRELV6503B14 / RGRELV6503B16
Material: Ductile Iron (Inlet Body), Cast Aluminum (Body & Bonnet)
Medium: LPG
Description
Technical Features of RegO LV6503B Series LPG Regulators:
- Multiple outlet pressure options available
- All-weather design
- Safe and simple operation
This is a second-stage regulator with an externally replaceable orifice for easy cleaning and maintenance. It features an internal parallel pivot design that ensures complete shutoff. The regulator uses a fabric-reinforced diaphragm with a reciprocating and diaphragm-molded design, offering precise and durable performance.
The large valve and bonnet openings are designed in accordance with UL standards and are equipped with filters and threaded interfaces. Widely used in industrial facilities, hotels, cafeterias, and LPG cylinder manifold systems. Certified by ISO 9001 and UL (USA).
Technical Specifications of RegO LV6503B Series LPG Regulators:
| 型号 | 进口尺寸 | 出口尺寸 | 可调压力范围 | 流量大小 |
|---|---|---|---|---|
| LV6503B14 | 1-1/2" F.NPT | 1-1/2" F.NPT | 216-356 | 188kg/hr |
| LV65503B16 | 2" F.NPT | 2" F.NPT | 222kg/hr |
Model: LV6503B14
RegO LV6503B14 LPG Gas Regulators
Brand: RegO (USA)
Model: LV6503B14
Inlet Size: ½" F.NPT
Outlet Size: ¾" F.NPT
Adjustable Pressure Range: 228–330 mm.wc
Flow Capacity: 188 kg/h
Product Code: RGRELV6503B14
Material: Ductile Iron (Inlet Body), Cast Aluminum (Body & Bonnet)
Medium: LPG
Model: LV65503B16
RegO LV65503B16 LPG Gas Regulators
Brand: RegO (USA)
Model: LV65503B16
Inlet Size: 2" F.NPT
Outlet Size: 2" F.NPT
Adjustable Pressure Range: 228-330 mm.wc
Flow Capacity: 222 kg/h
Product Code: RGRELV6503B16
Material: Ductile Iron (Inlet Body), Cast Aluminum (Body & Bonnet)
Medium: LPG
Additional information
| Brand |
RegO |
|---|
