Honeywell American Meter AC630 25psi LPG Diaphragm Meter City Natural Gas Flowmeter DN32
Brand: Honeywell
Model: AL630HOT
Connection size: 1 inch (20 LT), 1.25 inch (30 LT), 1.5 inch (45 LT)
Flow capacity: 630 SCFH (17.8 m³/h)
Allowable working pressure MAX: 25 PSI
Temperature compensation range: -30 ° F to 140 ° F (-34 ° C to 60 ° C)
Material: Die cast aluminum shell
Medium: LNG, city gas, LPG, air, inert gas, etc
Description
Honeywell American Meter AC-630 Diaphragm Meter
Designed to meter a variety of gases for large residential/commercial/small industrial applications at pressures up to 25 PSIG and flow rates to 630 SCFH at 1/2” W.C. differential pressure.
Features
Die-cast aluminum case
Oil-impregnated, self-lubricating bushings
Molded, convoluted diaphragms for smooth operation and long life
Rigid, reinforced flag rods for positive alignment and sustained accuracy
Graphite-filled phenolic valves to minimize wear
Long-life, low friction, grommet seals
Single coat polyester primer with high solids polyurethane top coat
Security seals that indicate tampering
Advantages
Temperature compensation available from -30°F to 140°F (-34°C to 60°C)
630 SCFH (17.8 m³/h) (0.60 specific gravity gas) at 1/2-inch W.C. differential
AMI/AMR compatibility
Meets ANSI B109.2 specifications
Measurement Canada accredited
Applications
The AC-630 is ideally suited for larger residential, commercial and small industrial installations. It is unequaled for accuracy retention and for life cycle maintenance economies.
Options
Regular or Temperature Compensated
Pointer or odometer index
2 ft³ or 0.05 m³ drive
20 LT, 30 LT, 45 LT and other connection sizes
25 PSIG (1724 mBar) Maximum Allowable Operating Pressure (MAOP)
Pressure compensating indexes
Standard or UV protected index covers
Meter bars
Connection sets
Remote Volume Pulsers
7” or 8.25” center-to-center connections
Capacities (0.60 specific gravity gas)
| Line Pressure PSIG (mbar) | Differential Inches W.C. (mbar) | Flow SCFH (m³/h) |
|---|---|---|
| 0.25 (17) | 1/2 (1.2) | 630 (17.8) |
| 0.25 (17) | 2 (5) | 1320 (37.4) |
| 1 (69) | 2 (5) | 1340 (37.9) |
| 2 (138) | 2 (5) | 1390 (39.4) |
| 5 (345) | 2 (5) | 1515 (42.9) |
| 10 (690) | 2 (5) | 1710 (48.4) |
| 15 (1035) | 2 (5) | 1890 (53.5) |
| 20 (1380) | 2 (5) | 2010 (56.9) |
| 25 (1724) | 2 (5) | 2160 (61.2) |
Special Gas Capacities
Propane: 397 cfh (11.2 m³/h)
Butane: 347 cfh (9.8 m³/h)
